Description
C450 Manual Traverse Fixed Ceiling Lifts by Handicare
The Handicare Manual Traverse C450 Fixed Ceiling Lift is the smallest in its range but can lift to 450 pounds. It uses a simple 2-button control to raise and lower patients.
While it doesn’t move sideways automatically, caregivers must manually adjust patients from side to side.
The lift comes in several versions: Traverse for general use, Traverse – Quick Curve for a Quick Curve track system, Rev A with updates, Rev A Curtain Jumping for curtain needs, and Traverse (Omni) for an Omni charge system.
This product is for the lift motor unit only. It includes:
-
C-450 ceiling lift motor
-
Pneumatic Hand control
-
Charger
-
Owner’s manual
Safe and Smooth Movement for Your Loved Ones
The Handicare C-450 Ceiling Lift offers a practical solution. It lets you transfer your family members smoothly between rooms, like from a bed to a wheelchair or into the bathroom, without any strain.
The easy-to-use hand pneumatic controller and quiet operation make every lift simple and safe. You can customize the track system to fit your home’s layout, ensuring a hassle-free experience. With the C-450, you can make daily movements more manageable and keep your loved one comfortable and secure in the home they cherish.
Features and Benefits
-
Smooth and Quiet: Enjoy easy, comfortable transfers with minimal noise.
-
Versatile Use: Handle various tasks like lifting, positioning, and turning with one device.
-
Simple Controls: Operate the lift easily with large, straightforward buttons.
-
Custom Track: Move around your home with a track system designed just for you.
-
Compact Design: Get strong support without bulky equipment in your home.
Documents
C450 Fixed Ceiling Lifts Manual
C450 Fixed Ceiling Lifts C Series Brochure
C450 Fixed Ceiling Lifts C Series Specs
Specifications
body { margin: 20px; } table { width: 100%; border-collapse: collapse; margin-bottom: 20px; } th, td { border: 1px solid #ddd; padding: 8px; text-align: left; } th { background-color: #f4f4f4; }
| Feature | C-450 |
|---|---|
| Motors | Lift Motor: 24 VDC Power Traverse: 24 VDC (Optional) X-Y Traverse: 24 VDC (Optional) |
| Safe Working Load (SWL) | 450 lb |
| Dimensions (L x W x H) | 12.5 x 5.7 x 8.6 inches |
| Unit Weight | 24 lb |
| Lift Case | Flame Retardant ABS |
| Safety Features | Emergency Stop Emergency Lowering Device Emergency Manual Lowering |
| Hand Control | Pneumatic |
| Service Life | 10 Years or 22,500 Cycles |
| Rated Performance (Number of Lifts) | 50-60 lifts at 450 lb |
| Batteries | Sealed Lead Acid, 24 VDC (2 x 12 VDC), 5.0 AH |
| Charger | Model: Soneil, PS2403SRM30 Input: 100-240 VAC, 50-60Hz, 1.5A Output: 24 VDC, 1.0 Amps |
| Lifting Range | Up to 96 inches |
| Duty Cycle | 1 Min “On” / 9 Mins “Off” |
Warranty Information
- Handicare guarantees all new equipment, including ceiling lifts, floor lifts, bathroom safety products, slings, service parts, tracks, and accessories, against failure for 1 year from the installation date or 18 months from the manufacturing date, whichever comes first.
