Phoenix Carbon Fiber Ultra-Light Electric Wheelchair — 27 Lbs

Description

Not All Wheelchairs Are the Same—Here’s Why the Phoenix Stands Out

The ComfyGO Phoenix Carbon Fiber Folding Electric Wheelchair is built for travelers who want freedom without the weight. At just 27 lbs, it supports up to 286 lbs and features an 18.5″ wide seat for everyday comfort.

Powered by two 250W brushless motors, it runs smoothly and quietly for up to 23 miles on its airline-approved dual 10AH batteries. The Phoenix folds in seconds, making it easy to carry, store, and take anywhere you go.

Precise Control and Seamless Mobility with the ComfyGo Phoenix

The Phoenix Folding Wheelchair is designed for optimal functionality and user convenience, featuring a 360-degree intelligent digital joystick with an easy-to-read LCD display. This advanced joystick allows for precise and effortless control, enabling smooth navigation in all directions and ensuring a seamless mobility experience. To give users added confidence in their investment.

Smooth Performance and Easy Terrain Navigation with the ComfyGo Phoenix

The Phoenix Carbon Fiber Electric Wheelchair is powered by two 250W brushless silent motors, delivering a combined 500W motor power for smooth and efficient performance. It is designed to handle various terrains with ease, including gravel, grass, ramps, and brick surfaces, thanks to its 6-degree climbing gradient capability. The intelligent electromagnetic brakes provide added safety and control, ensuring a secure and stable ride on all types of surfaces.

ComfyGo Phoenix Airline and Cruise Approved for Easy Travel

The Phoenix Carbon Fiber Lightweight Wheelchair is equipped with dual 10AH lithium-ion batteries that feature a quick-release function for easy removal, charging, or travel. These batteries are cruise and airline approved wheelchair, ensuring hassle-free travel. Together, they offer a driving range of up to 25 miles.

---

Phoenix Carbon Fiber Electric Wheelchair Essential Features

---

.image-container { display: flex; flex-wrap: wrap; justify-content: center; gap: 10px; padding: 10px; } .image-container img { max-width: 100%; height: auto; flex: 1 1 calc(50% – 10px); /* Adjust for spacing */ box-sizing: border-box; } @media (max-width: 600px) { .image-container img { flex: 1 1 100%; } } /* Scoped styling only for this section */ #youtube-video-section .youtube-container { display: flex; justify-content: center; align-items: center; margin: 20px auto; max-width: 800px; width: 100%; padding: 0 10px; } #youtube-video-section .video-wrapper { position: relative; width: 100%; max-width: 800px; padding-bottom: 62.5%; /* Keeps 16:10 ratio roughly (500/800 = 0.625) */ height: 0; } #youtube-video-section .video-wrapper iframe { position: absolute; top: 0; left: 0; width: 100%; height: 100%; border: none; } /* Optional: maintain small margins on mobile */ @media (max-width: 600px) { #youtube-video-section .youtube-container { padding: 0 5px; } }

---

Phoenix Carbon Fiber Electric Wheelchair Features and Benefits

---

• Lightweight (27 lbs): For lifting, carrying, and storage.

• Carbon Fiber Frame: Strong material with low weight.

• Dual Motors: Runs quietly on different surfaces.

• 360° Joystick with LCD Display: Gives directional control.

• Extended Range: Up to 25 miles per charge.

• Travel Friendly: Approved for airplane and cruise ship transport.

• Quick-Release Battery: Detachable for charging or transport.

• All-Terrain Use: Works on ramps, grass, gravel, and similar surfaces.

• Comfortable seating for long period use.

• Foldable Design: Folds for storage and transport in small spaces.

.image-container { display: flex; justify-content: space-between; margin: 20px; /* Added margin for spacing */ } .image-text { text-align: justify; margin-top: 10px; flex: 0 0 30%; /* Adjusted column width to 30% */ } .image-text img { max-width: 100%; /* Make sure images don’t exceed their container width */ height: auto; /* Maintain aspect ratio */ }

---

Phoenix Carbon Fiber Electric Wheelchair Document

---

ComfyGO Phoenix Manual

---

Phoenix Carbon Fiber Electric Wheelchair Specification

---

table { width: 100%; border-collapse: collapse; } th, td { padding: 10px; text-align: left; border: 1px solid #ddd; } th { background-color: #f2f2f2; } .section-title { background-color: #f2f2f2; font-weight: bold; }

• The main frame of the Phoenix Carbon Fiber Wheelchair weighs 27 lbs, making it the heaviest component of the wheelchair.
• The cushion, backrest, footrests, and controller together add a total of 3 lbs. Thus, the Phoenix weighs 29 lbs without the battery.
• Each 10AH battery adds 3 lbs to the weight. Therefore, the total weight of the Phoenix carbon fiber wheelchair with the battery is 35 lbs.

Parameters	Specifications
Capacity
Max Loading Weight	286 lbs
Weight
Frame Weight	27 lbs
Net Weight without Battery	29 lbs
Net Weight with Battery	35 lbs
Range
Range in 2 10AH Battery	Up to 25 miles
Dimensions
Overall Dimensions	35” x 22.5” x 34”
Folded Dimensions	3“ x 8.5” x 27”
Seat Height (from Ground)	18.5″
Armrest Height (from Seat)	8″
Backrest Height	16″
Performance
Max Speed	4 mph
Motor	2 * 250W (500W) Brushless
Climbing Angle (Max Degrees)	6°
Max Safe Slope	6°
Static Stability	6°
Brake	Intelligent Electromagnetic
Material
Battery	2x 24V 10AH Li-ion
Battery Charge	AC 100-240V, 50 Hz, 1.5-5A
Battery Charge Time	6-8 hours
Additional Features
Airline and Cruise Approved	Yes
Turning Radius	≤35.5″
Reversing Width	≤49″
Front Wheel Diameter	6″
Rear Wheel Diameter	10″
Seating Area Width	18.5″
Cushion Size	17″ x 16″
Controller Type	Detachable All Direction LCD Joystick
Tire Pressure	30 Psi

---

ComfyGo Phoenix Warranty

---

• The Phoenix comes with a standard 1-year frame, 1-year motor, 1-year battery, and 1-year electronic parts warranty.

.faq-list { list-style-type: none; padding: 0; } .faq-question { cursor: pointer; padding: 10px; background-color: #f2f2f2; border: 1px solid #ddd; text-align: left; margin-bottom: 5px; } .faq-answer { display: none; padding: 10px; margin-bottom: 5px; background-color: #ffffff; border: 1px solid #ddd; }

---

ComfyGO Phoenix FAQ

---

1. Can I turn my wheelchair on or off with the remote control?No. The wheelchair’s power must be turned on before the remote control is turned on…
2. Does my wheelchair arrive fully assembled?Your wheelchair will arrive almost fully assembled…
3. Can my wheelchair go on an airplane or cruise?Yes. The 10AH lithium-ion battery is travel approved by most major airlines…
4. I’ve run out of battery. Can I push my chair?Yes. The wheelchair can operate like a manual wheelchair…
5. Does my remote control come paired with my chair?Yes. The remote control comes paired with your chair. If your remote loses its pairing, please watch this video tutorial…
6. Can I silence the beeping sound my wheelchair makes while reversing?Yes. To remove the beeping noise, press the (+) key on the controller…
7. Does the armrest raise?Yes. Both armrests can raise to allow an easier exchange…
8. How do I charge the battery?The lithium-ion battery can be charged through the joystick controller or directly on the battery…
9. Can I install my controller on either side of the wheelchair?Yes. The controller will be set up on the right side…
10. Does my wheelchair come with a warranty?Yes. The Phoenix wheelchair comes with a standard 1-year frame, motor, battery, and electronic parts warranty.
11. Can I use my wheelchair on dirt and grass?Yes. The Phoenix can traverse low grass and compacted dirt with ease.
12. Where can I find the serial number of my wheelchair?The serial number can be found on the frame near the footrest, in the manual, and on the shipping box.
